Big Tex Heavy Duty Low Profile Dump Trailer | 14XD-14C2A

Description Part of the all-new X-Series, the 14EH Equipment Trailer from Big Tex Trailers is engineered for professionals who demand durability and innovation. The 14EH features APEX Fortified Lumber for superior deck durability and a Mega-Sized Toolbox for added storage capacity. It’s enhanced with a Full-Length Rub Rail, D-Rings, and Stake Pockets, providing multiple secure tie-down options for a variety of cargo. The 14EH revolutionizes loading and unloading with its optional Self-Stabilizing Mega Ramps, offering unparalleled flexibility for all your hauling needs. Standard Feature Available Options Axles 2 – 7,000# Premium, Cambered Axles with Quick-Lubricating Hubs Brakes Forward Self-Adjusting Electric Brakes on All Hubs Suspension Multi-Leaf Slipper Spring w/ Equalizer Coupler Adjustable 2-5/16” Demco EZ Latch Adjustable Pintle in Channel in Lieu of Coupler Adjustable 2-5/16″ Demco EZ Latch Gooseneck Coupler Safety Chains 3/8″ Grade 70 w/ Safety Latch Hook (2 ea) Jack 12,000# Drop-Leg Jack (Side Wind) Frame 8″ I-Beam Cross-Members 3″ Channel on 16″ Centers Front Stop Rail 3/16″ Fabricated Front Stop Rail Floor APEX Fortified Lumber Fenders 9” x 72” 14 Ga. Diamond Plate Double Square Broke w/Back (Removable) Ramps 5′ Tall, 16″ Stand Up Rams (Spring Assisted) 36″ Wide Mega Ramps (D3 Models Only) Super-Wide Ramps (60″ Tall x 30″ Wide) w/ Blackwood Pro-Filled Dovetail Dovetail 40” Cleated Dovetail Stake Pockets Stake Pockets Along Both Sides (Quantity Varies by Length) Trailer Plug 7-Way RV Lights L.E.D. D.O.T. Stop, Tail, Turn & Clearance Wiring Sealed, Modular Cold-Weather Wiring Harness Tires ST235/80 R-16 Load Range E Radial Tires Tire Upgrade (ST235/80 R-16 LR-G) Bolt Pattern 8-Lug Spare Mount Front Spare Tire Mount Spare Tire Not Included Spare Tire & Wheel (ST235/80 R-16 LR-E) Paint Color Black Red Grey White Desert Tan Jet Blue Slime Green Implement Green Equipment Orange Medium Yellow Rubrail Rub Rail Along Both Sides Tie-Downs (6) 5/8″ D-Rings Break-Away Kit Complete Breakaway System w/ Zip Breakaway Cable Storage Lockable Toolbox Between Risers on Gooseneck Model Mega-Sized Integrated Tongue Box with Lockable Lid (Bumper Pull Only) Steps & Handles Convenient Side-Step to Access Deck Model Pull Type GVWR GAWR (Ea. Axle) Empty Weight Cargo Capacity Bed Length Bed Width 14EH-16D3A Bumperpull 15400 lbs 7000 lbs 2860 lbs 12540 lbs 16′ 83″ 14EH-18D3A Bumperpull 15400 lbs 7000 lbs 3020 lbs 12380 lbs 20′ 83″ 14EH-20D3A Bumperpull 15400 lbs 7000 lbs 3150 lbs 12250 lbs 20′ 83″ 14EH-22D3A Bumperpull 15400 lbs 7000 lbs 3330 lbs 12070 lbs 22′ 83″ 14EHG-20D3A Gooseneck 15900 lbs 7000 lbs 3740 lbs 12160 lbs 22′ 83″ 14EHG-22D3A Gooseneck 15900 lbs 7000 lbs 3940 lbs 11960 lbs 22′ 83″ 14EHG-24D3A Gooseneck 15900 lbs 7000 lbs 4140 lbs 11760 lbs 22′ 83″
